I. Product Overview
This upright SMT-mounted Type-C male header features an innovative 16-pin configuration with a compact 10.95mm profile, engineered for high-density PCB integration and space-constrained devices. Constructed with stainless steel 304 housing, it provides dual manufacturing options—precision stamping or riveted assembly—to deliver robust performance across consumer electronics, industrial systems, and mission-critical applications.
II. Core Specifications
· Interface Type: USB Type-C male connector (16-pin, reversible plug design)
· Mounting Method: Vertical SMT for seamless automated manufacturing processes
· Dimensions: 10.95mm height, enabling ultra-slim device architectures
· Housing Material: Grade 304 stainless steel (anti-corrosion, mechanical resilience)
· Construction Options:
o Stamped Housing: Single-piece design with precision molding, achieving IP67-rated sealing for harsh environments (e.g., outdoor, marine).
o Riveted Housing: Modular assembly with reinforced mechanical stability, ideal for shock/vibration-prone settings (e.g., automotive, heavy machinery).
III. Electrical Properties
· High-Power Delivery: Supports 5A/20V operation with USB PD 3.0 compliance for rapid-charging systems and high-current peripherals.
· Ultra-Fast Data Rates: USB 3.1 Gen2 compatibility ensures 10Gbps throughput, enabling real-time 4K video streaming and large-file transfers.
· Optimized Conductivity: <30mΩ contact resistance and impedance-controlled terminals preserve signal fidelity in high-frequency applications.
· Safety Compliance: 500V AC insulation withstand voltage, certified to UL/IEC standards for fail-safe operation under electrical stress.
IV. Application Scope
· Smart Devices: Space-efficient charging/data ports for ultrabooks, tablets, and foldable phones requiring high-speed PD charging.
· Industrial Automation: Ruggedized connectivity for PLCs, robotic arms, and CNC systems where vibration resistance is critical.
· Automotive Tech: Temperature-stable interfaces for EV charging modules and ADAS control units (-40°C to +105°C operational range).
· Medical Technology: Hermetically sealed connections for autoclave-compatible diagnostic tools and surgical equipment.
· IoT & Outdoor Gear: Weatherproof endpoints for smart agriculture sensors, drone charging docks, and marine navigation systems.
V. Key Advantages
· Extended Lifespan: Stainless steel housing paired with 15μ" gold-plated terminals ensures >10k mating cycles under extreme conditions.
· Configurable Solutions: Dual housing methodologies + customizable options (selective Au/Ni plating, EMI shielding variants).
· Production Efficiency: Reflow-solderable SMT pads enable high-throughput PCB assembly with ±0.1mm placement accuracy.
· Sustainability: RoHS 2.0/REACH compliance with halogen-free materials, supporting circular manufacturing initiatives.
· Universal Compatibility: Hot-plug functionality across Windows, Android, macOS, and Linux ecosystems without driver dependencies.
· Technical Partnership: DFM analysis and 24/7 engineering support for rapid prototyping and production scaling.
Engineered for next-gen connectivity demands, this upright Type-C SMT connector combines military-grade durability with cutting-edge signal integrity. Its adaptive stamped/riveted architectures address both EMI-sensitive wearable designs and mechanically challenging M2M installations, setting new benchmarks for cross-industry interoperability.
Contact our team for datasheets, 3D models, or application-specific customization!
