Product specifications:
1-1. Insertion force: 35N MAX
1-2. Pulling force: 10N MIN.INITIAL 8-20N AFTER
1-3. Rated current: 3A
1-4. Rated voltage: 30V
1-5. Durability: 3000 Cycles MIN
1-6. Voltage endurance: 500V AC MIN
1-7. Contact impedance: 30M Ω MAX.INITIAL, 40M Ω MAX
1-8. Insulation resistance: 1000M Ω MAX
1-9. Working temperature: -40 degrees TO+70 degrees
Product Material:
2-1. Rubber core: PBT/LCP UL94V-0
2-2. Terminal: brass C2682 H65, nickel base, gold plated contact point 1U
2-3. Shell: SPCC/C2680 full area nickel plated 40U MIN
